Hydraulic Jacks
Technical Parameters
CAPACITY 5 to 100 TONNE
Capacity |
Tonne |
3 |
5 |
8 |
10 |
12 |
15 |
20 |
25 |
30 |
40 |
50 |
75 |
100 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
mm |
240 |
245 |
245 |
245 |
245 |
250 |
250 |
270 |
270 |
275 |
275 |
275 |
300 |
Hydraulic Lift 'B' |
mm |
120 |
150 |
150 |
150 |
150 |
150 |
150 |
150 |
150 |
150 |
150 |
150 |
150 |
Screw Extension 'C' |
mm |
75 |
100 |
100 |
100 |
100 |
100 |
100 |
* |
* |
* |
* |
* |
* |
Total Ext. Height "D" |
mm |
435 |
495 |
495 |
495 |
495 |
500 |
500 |
420 |
420 |
425 |
425 |
425 |
450 |
Ram Dia 'E' |
mm |
40 |
43 |
45 |
47 |
55 |
63 |
70 |
74 |
79 |
89 |
100 |
100 |
127 |
Body Dia 'F' |
mm |
80 |
80 |
90 |
90 |
100 |
115 |
127 |
140 |
152 |
180 |
203 |
215 |
240 |
Base Size 'G' |
mm |
115*
|
115*
|
145*
|
145*
|
160*
|
160*
|
180*
|
190*
|
190*
|
200*
|
220*
|
225*
|
310*
|
Pump Piston 'H' |
No. |
One |
One |
One |
One |
One |
One |
One |
One |
One |
One |
Two |
Two |
Two |
Working Pressure 'I' |
Kg/cm2 |
250 |
290 |
450 |
450 |
405 |
405 |
420 |
520 |
490 |
540 |
540 |
540 |
540 |
Oil Requirement |
Ltr. |
0.3 |
0.4 |
0.6 |
0.6 |
0.8 |
0.8 |
1.5 |
1.5 |
1.5 |
2.0 |
2.5 |
3.0 |
4.0 |
Weight Approx |
Kgs. |
8.0 |
9.0 |
10.0 |
12.5 |
14.0 |
17.0 |
26.0 |
28.0 |
30.0 |
37.5 |
58.0 |
75 |
95 |
1. Manufacturing tolerance ± 5 mm.
2. The Specification, illustration and Description are only Indecative & Subject to change without notice.
3. Jacks can be also supplied other than above specification- Horizontally and Vertically as per Customer requirements.
4. Pressure Gauge with Calebration direct in Tonne can be supplied against order
